powerstar

Make: Weichai Euro 2 Intercooled
Model Configuration: WP 12.420 E32
Max Power—Kw @ r/min: 309/2200
Max Power—N.m @ r/min: 1750/1300-1400
HP: 420
Cylinder: 6 Inline
Water Cooled: Yes
Direct Injection: Yes
Engine driven P.T.O: No
Displacement (l): 11.596
Compression Ratio: 17:01

Service :Double circuit air brakes
Emergency / Parking: Spring potential brake
Auxiliary: ABS & EVB

Size and ply rating: 315x80R22.5 incl spare wheel

Type: VR4/01D-7.5
Suspension: Non-free standing stabilization leafspring, hydraulic shock absorber, transverse stabilizer

Type: HL7/015DS-13/4.2
Suspension Stabilizator: suspension, 13 pcs leaf spring (each 20mm)

Alternator: 55Amp
Starter Motor: 5.58kW
Batteries: 2 x 12V – 135AH

Gradeability: @ GVM 24% @ GVM
Max Geared Road Speed: 105km/h
Final Drive Ratio: 4.769

Make / Type / Size: GFX 430mm single
Operation: Single dry frictional disc, diaphragm spring, pulling type

New Vehicle: 3 years / 300 000km (SA only)

Make/Model: 12JS200TA + QH50
No of Gears: 12
Synchromesh or Constant Mesh Synchromesh P.T.O: Yes

Overall Length (OL): 6 935

Overall Width (OW): 2 495

Overall Height (OH): 3 160

Front Overhang (FOH): 1 410

Rear Overhang (ROH): 625

Wheel Base (WB): 4 175

Bumper to Back of Cab (BBC): 2 420

Cab to rear axle / unit (CA): 3 165

Turning Circle (TC): 8 500

Fuel Tank Capacity: 400l

Manufacturers Gross Vehicle Mass (GVM): 26 000

Manufacturers Gross Combination Mass (GCM): 65 000

Manufacturers Front Axle mass (GA): 7 500

Manufacturers Rear Axle mass (GAU): 26 000

Permissible Maximum Vehicle Mass (V): 25 500

Permissible Maximum Front Axle Mass (AF): 7 500

Permissible Maximum Rear Axle Mass (AR): 18 000

Unladen Front Axle Mass (UF): 4 700

Unladen Rear Axle Mass (UR): 4 900

Total Unladen Mass (UT): 9 600

Permissible Max Drawing Vehicle Mass (D/T): 65 000
