powerstar

Make Cummins Euro III

Model Confirguration ISF3.8s3168

Max Power - Kw @ r/min 125/2600

Max Torque - N.m @ r/min 600/1500~1700

HP 170

Cylinder 4 Inline

Water Cooled Yes

Direct Injection Yes / Common Rail

Engine Driven P.T.O No

Displacement (I) 3.76

Compression Ratio 17.2:1

Service Air Brake

Emergency / Parking NA

Auxiliary Exhaust Brake

Size and ply rating 8.25R20

Type Forged I-beam

Suspension Non-independent, front and rear leaf spring

Type Integral

Suspension Non-independent, front and rear leaf spring

Alternator 70 Amp

Starter Motor 24 Volt/3.6 kW

Batteries 2 x 12V - 100Ah

Gradeability @ GVM 30%

Max Geared Road Speed 105 km/h

Final Drive Ratio 5,286

Make / Type / Size 362

Operation Diaphragm spring clutch

New Vehicle 2 Years Unlimited

Make/Model ZF Ecolite 6S600

No Gears 6

Synchromesh or Constant Mesh Synchromesh

Transfer Box NA

P.T.O No - PTO Interface Only

Overall Length (OL) 8 715

Overall Width (OW) 2 303

Overall Height (OH) 2 510

Front Overhang (FOH) 1 195

Rear Overhang (ROH) 2 320

Wheel Base (WB) 5 200

Bumper to Back of Cab (BBC) 1 960

Cab to rear axle / unit (CA) 4 435

Turning Radius (TR) 11

Fuel Tank Capacity (FTC) 200

Manufacturers Gross Vehicle Mass (GVM) 13 095

Manufacturers Gross Combination Mass (GCM) 17 000

Manufacturers Front Axle Mass (GA) 4 500

Manufacturers Rear Axle Mass (GAU) 9 000

Permissible Maximum Vehicle Mass (V) 13 095

Permissible Maximum Front Axle Mass (AF) 4 500

Permissible Maximum Rear Axle Mass (AR) 9 000

Unladen Front Axle Mass (UF) 2 120

Unladen Rear Axle Mass (UR) 1 760

Total Unladen Mass (UT) 3 880

Permissible Max Drawing Vehicle Mass (D/T) 17 000

Day Cab: Yes
